Configuration Procedure:

Step Operation Description

Set the link type for port. Required. On the VLAN→802.1Q VLAN→Port Config page,

set the link type for the port basing on its connected device.

Create VLAN. Required. On the VLAN→802.1Q VLAN→VLAN Config

page, click the Create

button to create a VLAN. Enter the

VLAN ID and the description for the VLAN. Meanwhile,

specify its member ports.

Create Protocol Template. Required. On the VLAN→Protocol VLAN→Protocol

Template page, cr

eate the Protocol Template before

configuring Protocol VLAN.

Create Protocol VLAN. Required. On the VLAN→Protocol VLAN→Protocol

Group page, select the protocol name and enter the VLAN

ID to create a Protocol VLAN.

Meanwhile, enable protocol

VLAN for ports.

Modify/View VLAN. Optional. On the VLAN→Protocol VLAN→Protocol

Group Table page, click the Edit button to modify/view the

information of the corresponding VLAN.

Delete VLAN. Optional. On the VLAN→Protocol VLAN→Protocol

Group Table page, select the d

esired entry to delete the

corresponding VLAN by clicking the Delete button.

7.6 Application Example for Protocol VLAN

 Network Requirements

 Department A is connected to the company LAN via Port12 of switch A;

 Department A has IP host and AppleTalk host;

 IP host, in VLAN10, is served by IP server while AppleTalk host is served by AppleTalk server;

 Switch B is connected to IP server and AppleTalk server.
