9
LEDs
LED
Status
Indication
PWR
On
The switch is powered on
Off
The switch is powered off or power supply is abnormal
Flashing
Power supply is abnormal
System
Flashing
The switch works properly
On/Off
The switch works improperly
RPS
On
Green
Both the built-in power supply and the redundant power
supply work properly
Yellow
The built-in power supply works improperly, but the
redundant power supply works properly
Off
The switch is not connected to any redundant power supply
FAN
Green
All the fans work properly
Yellow
Not all the fans work properly
Master
On
The switch works as master in the stack system, or does not
join any stack system
Off
The switch works as slave in the stack system
Module
On(green)
An Interface Card is connected to the switch and works
properly
Flashing(yellow)
An Interface Card is connected to the switch, but works
improperly
Off
No Interface Card is connected to the switch
Link/Act
(Port 1-24)
Green
On
A 1000Mbps device is connected to the corresponding port,
but no activity
Flashing
Data is being transmitted or received
Yellow
On
A 10/100Mbps device is connected to the corresponding
port, but no activity
Flashing
Data is being transmitted or received
21F-24F
On
An SFP transceiver is connected to the corresponding port,
and it is connected to a device, but no activity
Flashing
A 1000Mbps device is connected to the corresponding port
and transmitting data
Off
An SFP transceiver is connected to the corresponding port,
but it is not connected to a device, or no SFP transceiver is
connected
