369
The following entries are displayed on this screen:
Graphic Show
Collect Topology: Click the Collect Topology button to display the cluster topology.
Refresh: Click the Refresh button to refresh the cluster topology.
Manage:
If the current device is the commander switch in the cluster and
the selected device is a member switch in the cluster, you can
click the Manage button
to log on to Web management page of
the corresponding switch.
Global configuration procedure of the Cluster function:
Before configuring a cluster, you should make clear the role each device will play in the cluster in
advance and make sure the devices in the cluster can communicate with each other.
To configure the switch to be a commander switch in the cluster, please take the following
steps.
Step Operation Description
1
Enable the NDP function
globally and for the port,
and then configure NDP
parameters
Optional. On Cluster→NDP→NDP Config page, enable the
NDP function on the switch.
2
Enable the NTDP function
globally and for the port,
and then configure NTDP
parameters
Optional. On Cluster→NTDP→NTDP Config page, enable
the NTDP function on the switch.
3 Establish a cluste
r and
configure the related
parameters
Optional. On Cluster→Cluster→Cluster Config page,
establish a cluster and configure the related parameters.
4
Manage the device in the
cluster
Optional. On Cluster→Cluster→Member Config page,
select the desired member switches and click the Manage
button to log on to its Web management page for
configuration.
Or
On Cluster→Cluster→Collect Topology page, double-
click the icon of the switch to view its detailed information;
click the icon, and then click the Manage button to log on to
its Web management page for configuration.
To configure the switch to be a member switch in the cluster, please take the following steps.
Step Operation Description
1
Enable the NDP function
globally and for the port,
and then configure NDP
parameters
Optional. On Cluster→NDP→NDP Config
page, enable the
NDP function on the switch.
