Chapter 13 Fault Codes and Descriptions AFE2000 Series
13-105
Fault Name Fault Descriptions Corrective Actions
cd1
Ias sensor err
Fault
R-phase error
Reboots the power. If fault code is still appears
on the keypad please return to the factory
cd2
Ibs sensor err
Fault
S-phase error
T-phase error
Reboots the power. If fault code is still appears
on the keypad please return to the factory
cd3
Ics sensor err
Fault
W-phase error
Reboots the power. If fault code is still appears
on the keypad please return to the factory
Hd0
cc HW error
Fault
cc (current clamp)
Reboots the power. If fault code is still appears
on the keypad please return to the factory
Hd1
Oc HW error
Fault
oc hardware error
Reboots the power. If fault code is still appears
on the keypad please return to the factory
Hd2
Ov HW error
Fault
ov hardware error
Reboots the power. If fault code is still
displayed on the keypad please return to the
factory
Hd3
occ HW error
Fault
occ hardware error
Reboots the power. If fault code is still
displayed on the keypad please return to the
factory
EF
External fault
Fault
External fault
1. When EF (N.O.) external terminal is ON.
AC motor drive stop output.
2. Press RESET after fault has been
cleared.
EF1
Emergency stop
Fault
Emergency stop
1. When the multi-function input terminals
MI1 to MI6 are set to emergency stop,
the AC motor drive stops output.
2. Press RESET after fault has been
cleared.
Pcod
Password error
Fault
Wrong password input
(3 times)
1. Refer to Pr.00-07 and 00-08.
2. Turn off the power then turn it on again
and enter the correct password.
