Delta Electronics REG300A23A-21 [86/131] Electricity cost

Chapter 11 Description of Parameter SettingsAFE2000 Series

11-84

Work Delete

Factory Setting: 0

Settings 0: Parameter return to home setting

1: Delete (when deleting is completed, Pr.03-12 reset to 1)

 When Pr.03-12 is set to 1, Pr.00-07 to Pr.00-12 will be deleted and set to 0 and when this process

is completed, Pr.03-12 return to 0.

Electricity cost

Factory Setting: 3.0

Settings 0~6553.5
