Chapter 11 Description of Parameter SettingsAFE2000 Series
11-96
CANopen Warning Record
Factory Setting: Read only
Settings
bit 0：CANopen Guarding Time out
bit 1：CANopen Heartbeat Time out
bit 2：CANopen SYNC Time out
bit 3：CANopen SDO Time out
bit 4：CANopen SDO buffer overflow
bit 5：Can Bus Off
bit 6：Error protocol of CANOPEN
Communication Card Firmware Version
Factory Setting: ##
Settings
Read only
Product Code
Factory Setting: ##
Settings
Read only
Fault Code
Factory Setting: ##
Settings
Read only
Communication Card Address
Factory Setting: ##
Settings DeviceNet: 0-63
Profibus-DP: 1-125
Setting of DeviceNet Speed
Factory Setting: 2
Settings Standard DeviceNet:
0: 100Kbps
1: 125Kbps
2: 250Kbps
3: 1Mbps (Delta only)
Non standard DeviceNet: (Delta only)
0: 10Kbps
1: 20Kbps
2: 50Kbps
3: 100Kbps
4: 125Kbps
