Chapter 10 Summary of Parameter SettingsAFE2000 Series
10-66
01 Basic Parameter
Parameter Explanation Settings
Factory
Setting
01-00 Parameter Reset 0: No function
1: Read only, write is disable
8: Keypad lock
10: All parameters are reset to the factory settings
0
01-01 Start-up Screen Display 0: Mains input frequency
1: DC BUS voltage
2: Output current
0
01-02
Password Input
1~9998, 10000~65535
0~2: times of wrong password input
0
01-03
Password Set
1~9998, 10000~65535
0: No password set or successful input in Pr.01-02
1: Password has been set, parameter is locked
0
01-04 Source of the Operation
Command
1: External terminal
2: RS-485 serial communication or digital keypad
(KPVL-CC01)
2
01-05
Control Mode Selection
0: AFE mode
1: Regenerate mode
0
01-06 Accel. Time 0.00~600.00 sec 2
01-07 Decel. Time 0.00~600.00sec 2
01-08 DC BUS Voltage Command 220V : 300~370V
440V : 600~740V
340
680
01-09 DC BUS Gain Ratio of P 0~100% 100
01-10 DC BUS Gain Ratio of I 0~100% 100
01-11 DC BUS Bandwidth Control 0~75
230V, 7.5kW
460V, 7.5kW
460V, 15kW
230V, 15kW
230V, 22kW
460V, 22kW
230V, 37kW
460V, 37kW
460V, 45kW
460V, 75kW
18
18
18
22
22
22
22
22
22
22
01-12 Inductance Value of Reactor 0(230V, 7.5kW): 2.10
1(460V, 7.5Kw): 7.32
2(230V, 15kW): 1.32
3(460V, 15kW): 5.28
4(230V, 22kW): 0.88
5(460V, 22kW): 3.52
6(230V, 37kW): 0.50
7(460V, 37kW): 1.96
9(460V, 45kW): 1.76
11(460V, 75kW): 1.02
0.88
