Chapter 10 Summary of Parameter SettingsAFE2000 Series
10-64
Parameter
Explanation
Settings
Factory
Setting
Regenerated
00-13 Display AFE2000 Internal
Temperature (℃)
Read only Read only
00-14
IGBT Temperature (℃)
Read only Read only
00-15 Digital Input Status
(ON/OFF )
Read only Read only
00-16 Digital Output Status
(ON/OFF)
Read only Read only
00-17 DC Bus Voltage at Fault Read only Read only
00-18 Mains Input Frequency at
Fault
Read only Read only
00-19 Current value at Fault Read only Read only
00-20 1
st
Recent Fault Record
Fault
Retry
Fault
Reset
Read only
00-21 2
nd
Recent Fault Record 0: No Fault Record
O
O
Read only
00-22 3
rd
Recent Fault Record 3 : ocn
Read only
00-23 4
th
Recent Fault Record 4: GFF O O
Read only
00-24 5
th
Recent Fault Record 5 : occ (only for frame D) O O
Read only
00-25 6
th
Recent Fault Record 6: ocs O O
Read only
9: oVn O O
10: oVs O O
13 : LVn
14: LVs O O
15: PHL (Input phase loss) O O
16: oH1 (IGBT over-heat) O O
17: oH2 (Capacitance over-heat) O O
18: ot1 (circuit error)
19: ot2 (circuit error)
20: oL (150% 1Min, AFE2000
over-load)
O O
30: cF1 (Memory write-in error)
31: cF2 (Memory read error)
32: cd0 Isum current detection
error
33: cd1 U-phase current detection
error
34: cd2 V-phase current detection
error
35: cd3 W-phase current
detection error
36: Hd0 cc current detection error
37: Hd1 oc current detection error
38: Hd2 ov current detection error
47: S1 Enable Error O
48: BST Voltage boosting error O
49: EF1 O O
52: PcodE Code error O
54: cE1 communication error
(warn)
O O
55: cE2 communication error
(warn)
O O
56: cE3 communication error
(warn)
O O
57: cE4 communication error
(warn)
O O
