Chapter 10 Summary of Parameter SettingsAFE2000 Series
10-68
03 Special Protection Parameters
Parameter Explanation
Settings
Factory
Setting
03-00 Low Voltage Level 230V model: 160.0~220.0Vdc
460V model: 320.0~440.0Vdc
180
360
03-01 Current Limit (Drive) 0~250% 150
03-02 Current Limit (Regeneration ) 0~250% 150
03-03 Phase Lock Frequency
Deviation Level
0.00~10.00Hz 4.00
03-04 Phase Lock Frequency
Deviation Time
0~1000ms 150
03-05 IGBT Temperature Warning
Level
0.0~110.0 ℃
100.0
03-06 Ambient Temperature
Warning Level
0.0~110.0 ℃
60.0
03-07 Numbers of Fault Retry 0~10 0
03-08 Fault Retry Reset Time 1~600 sec 600
03-09 Fan Control
(only ON/OFF for Frame B)
0: Fan is always ON
1: As the drive stops, the fan will continue to run for
60 sec then stop.
2: Fan stops when the drive stops operation
3: Fan ON/OFF depends on the ambient
temperature
4: Fan is always OFF
2
03-10 Voltage Boosting Error (Level
Setting)
0.0V ~15.0V 5.0
03-11 Voltage Boosting Error (Time
Setting)
200ms~1000ms 200
03-12 Work Delete 1: Delete (when deleting is completed, Pr.03-12
reset to 1)
0
03-13 Electricity cost 0~6553.5 3.0
