Chapter 11 Description of Parameter SettingsAFE2000 Series
11-95
12：8，N，1 for RTU
13：8，N，2 for RTU
14：8，E，1 for RTU
15：8，O，1 for RTU
16： 8，E，2 for RTU
17：8，O，2 for RTU
Communication Card Type
Factory Setting: Read only
Settings
0：no communication card
1：DeviceNet Slave
2：Profibus-DP Slave
3：CANopen Slave/Master
4：Modbus-TCP Slave
5：EtherNet/IP Slave
6~8：Reserved
CANopen Baud Rate
Factory Setting: 0
Settings 0: 1M
1: 500k
2: 250k
3: 125k
4: 100k (Delta only)
5: 50k
CANopen Slave Address
Factory Setting: 0
Settings 0: Disable
1~127
CANopen Communication Status
Factory Setting: Read only
Settings
0: Node Reset State
1: Com Reset State
2: Boot up State
3: Pre Operation State
4: Operation State
5: Stop State
