Chapter 11 Description of Parameter SettingsAFE2000 Series
11-73
Chapter 11 Description of Parameter Settings
00 Display Parameters This parameter can be set during the operation.
Identity Code of AFE2000
Factory Setting: Read only
Settings Display is different for different models. Read only.
Display AFE2000 Rated Current
Factory Setting: Read only
Settings Display is different for different models. Read only.
Pr. 00-00 displays the identity code of the AC motor drive. Using the following table to check if
Pr.00-01 setting is the rated current of the AC motor drive. Pr.00-01 corresponds to the identity
code Pr.00-01.
The factory setting is the rated current for normal duty.
Pr.00-00 disaplays the identity code of AFE2000 and the code is set by the factory. Pr.00-01 is the
rated current corresponds to its AFE2000 model (Pr.00-01). The corresponding current is shown at
following:
AFE2000 Corresponding Chart
Input voltage 230V 460V
Pr.00-00
0 2 4 6 1 3 5 7 9 11
Applicable power
range of AC motor
drive (kW)
75 15 22 35 7.5 15 22 37 45 75
Rated input current 35 70 95 150 20 35 50 75 95 160
Software version
Factory Setting: #.##
Settings Read only (The display content is different by factory version.)
Current of AFE Unit
Factory Setting: #.##
Settings Read only (The display content is different by factory version.)
Mains Input Frequency (Line frequency)
Factory Setting: #.##
Settings Read only (The display content is different by factory version.)
DC-BUS voltage
Factory Setting: #.##
Settings Read only (The display content is different by factory version.)
Display the Input Power of AFE2000 (kW )
Factory Setting: #.##
Settings -300.0~300.0
Display the Amount of Power Consumed kWh (High Word)
Factory Setting: #.##
Settings 0~9999
Display the Amount of Power Consumed kWh (Low Word)
Factory Setting: #.##
Settings 0~9999
Display the Amount of Power Regenerated kWh (High Word)
Factory Setting: #.##
Settings 0~9999
