Delta Electronics REG300A23A-21 [101/131] Chapter 12 warning codes

Chapter 12 Warning Codes AFE2000 Series

12-99

Chapter 12 Warning Codes

CE01

Comm. Error 1

Warning

Abbreviate error c ode

The code is displayed as shown on KPC-CE01.

Disp lay error signal

Disp lay error description

Display on LCM Keypad Descriptions

CE01

Comm. Error 1

Warning

Modbus function code error

CE02

Comm. Error 2

Warning

Address of Modbus data is error

CE03

Comm. Error 3

Warning

Modbus data error

CE04

Comm. Error 4

Warning

Modbus communication error

CE10

Comm. Error 10

Warning

Modbus transmission time-out

CP10

Keypad time out

Warning

Keypad transmission time-out

SE1

Save Error 1

Warning

Keypad COPY error 1

SE2

Save Error 2

Warning

Keypad COPY error 2

oH1

Over heat 1 warn

Warning

IGBT over-heating warning
