Chapter 12 Warning Codes AFE2000 Series

12-100

oH2

Over heat 2 warn

Warning

Capacity over-heating warning

PHL

Phase Loss

Warning

Phase loss

CGdn

Guarding T-out

Warning

CAN guarding time-out 1

CHbn

Heartbeat T-out

Warning

CAN heartbeat time-out 2

CSYn

SYNC T-out

Warning

CAN synchrony time-out

CbFn

Can Bus Off

Warning

CAN bus off

CSdn

SDO T-out

Warning

CAN SDO transmission time-out

CSbn

Buf Overflow

Warning

CAN SDO received register overflow

Cbtn

Boot up fault

Warning

CAN boot up error

CPtn

Error Protocol

Warning

CAN format error

CIdn

Warning

CAN/S Idx exceed

CAN index error

CAdn

Warning

CAN/S Addres set

CAN station address error

PCGd

Warning

CAN/M Guard err

CAN Master guarding error
