Chapter 12 Warning Codes AFE2000 Series
12-101
PCbF
Warning
CAN/M bus off
CAN Master bus off
PCnL
Warning
CAN/M Node Lack
CAN Master node error
PCCt
Warning
CAN Master cycle time-out
PCSF
Warning
CAN/M SDO over
CAN Master SDO over
PCSd
Warning
CAN/M Sdo Tout
CAN Master SDO time-out
PCAd
Warning
CAN/M Addres set
CAN Master station address error
ECid
ExCom ID failed
Warning
Duplicate MAC ID error
Node address setting error
ECLv
ExCom pwr loss
Warning
Low voltage of communication card
ECtt
ExCom Test Mode
Warning
Communication card in test mode
ECbF
ExCom Bus off
Warning
DeviceNet bus-off
ECnP
ExCom No power
Warning
DeviceNet no power
ECFF
ExCom Facty def
Warning
Factory default setting error
ECiF
ExCom Inner err
Warning
Serious internal error
