Chapter 12 Warning Codes AFE2000 Series
12-102
ECio
ExCom IONet brk
Warning
IO connection break off
ECPP
ExCom Pr data
Warning
Profibus parameter data error
ECPi
ExCom Conf data
Warning
Profibus configuration data error
ECEF
ExCom Link fail
Warning
Ethernet link fail
ECto
ExCom Inr T-out
Warning
Communication time-out for communication card and drive
ECCS
ExCom Inr CRC
Warning
Check sum error for communication card and drive
ECrF
ExCom Rtn def
Warning
Communication card returns to default setting
ECo0
ExCom MTCP over
Warning
Modbus TCP exceed maximum communication value
ECo1
ExCom EIP over
Warning
EtherNet/IP exceed maximum communication value
ECiP
ExCom IP fail
Warning
IP fail
EC3F
ExCom Mail fail
Warning
Mail fail
Ecby
ExCom Busy
Warning
Communication card busy
