Chapter 14 CANopen Overview AFE2000 Series
14-118
14.4 CANopen Supporting Index
Basic Index Support by AFE2000:
Index
Sub
Definition Default Setting
R/W
Size
Note
1000H 0 Device type 00010192H
R
U32
1001H 0 Error register 0
R
U8
1005H 0 COB-ID SYNC message 80H
R
U32
1006H 0 Communication cycle period 0
RW
U32
Unit: us
The setting value should be in a
multiple of 500us (integer) and
within the range 500us to 16ms
1008H 0 Manufacturer device name 0
R
U32
1009H 0 Manufacturer hardware version 0
R
U32
100AH 0 Manufacturer software version 0
R
U32
100CH 0 Guarding time 0
RW
U16
Unit: ms
100DH 0 Guarding factor 0
RW
U8
0 Store Parameter 2
R
U8
1 Save all parameters 0
RW
U32
1010H
2
Save communication
parameter
1
RW
U32
0 Restore Parameter 2
R
U8
1 Restore all parameters 0
RW
U32
1011H
2
Restore communication
parameter
1
RW
U32
1014H 0 COB-ID emergency 0000080H+Node-ID
R
U32
1015H 0 Inhibit time EMCY 0
RW
U16
Unit: 100us
The setting value should be in a
multiple of 10 (integer).
0 Consumer heartbeat time 1
R
U8
1016H
1 Consumer 1 0
RW
U32
Unit: 1ms
Disable Guarding time to
function properly,
1017H 0 Producer heartbeat time 0
RW
U16
Unit: 1ms
Disable Guarding time to
function properly.
0 Number 0
R
U8
1 Vender ID 000001DDH
R
U32
2 Product code 2A00+machine code
R
U32
1018H
3 Revision 00010000H
R
U32
0 Server SDO Parameter 2
R
U8
1 COB-ID Client -> Server 0000600H+Node-ID
R
U32
1200H
2 COB-ID Client <- Server 0000580H+Node-ID
R
U32
0 Number 2
R
U8
1 COB-ID used by PDO 00000200H+Node-ID
RW
U32
00:Acyclic& Synchronous
01~240:Cyclic & Synchronous
1400H
2 Transmission Type 5
RW
U8
255:Asynchronous
0 Number 2
R
U8
1401H
1 COB-ID used by PDO 80000300H+Node-ID
RW
U32
