Chapter 7 Option CardsAFE2000 Series
7-49
Electrical Specification
Power supply voltage 5VDC (supplied by AFE2000)
Insulation voltage
500VDC
Communication wire
power consumption
0.85W
Power consumption 1W
Weight 23g
Environment
Noise immunity
ESD (IEC 61800-5-1,IEC 6100-4-2)
EFT (IEC 61800-5-1,IEC 6100-4-4)
Surge Teat(IEC 61800-5-1,IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1,IEC 6100-4-6)
Operation /storage
Operation: -10ºC ~ 50ºC (temperature), 90% (humidity)
Storage: -25ºC ~ 70ºC (temperature), 95% (humidity)
Shock / vibration
resistance
International standards: IEC61131-2, IEC68-2-6 /IEC61131-2 & IEC 68-2-27
DeviceNet Connector
PIN Signal Color Definition
1 V+ Red DC24V
2 H White Signal+
3 S - Earth
4 L Blue Signal-
5 V- Black 0V
5
4
3
2
1
LED Indicator & Troubleshooting
There are 3 LED indicators on CMC-DN01. POWER LED displays the status of power supply. MS LED and NS
LED are dual-color LED, displaying the connection status of the communication and error messages.
POWER LED
LED status Indication Treatment
On Power supply in abnormal status.
Check the power supply of CMC-DN01.
Off Power supply in normal status --
