Chapter 11 Description of Parameter SettingsAFE2000 Series
11-92
Content Address Function
Bit 0-3
0: No function
1: Stop
2: Run
3: No function
Bit 4-5
00B: No function
01B: No function
10B: No function
11B: No function
Bit 6-7
00B: No function
01B: No function
10B: No function
11B: No function
Bit 8-11 0000B: No function
0001B: No function
0010B: No function
0011B: No function
0100B: No function
0101B: No function
0110B: No function
0111B: No function
1000B: No function
1001B: No function
1010B: No function
1011B: No function
1100B: No function
1101B: No function
1110B: No function
1111B: No function
Bit 12 1: No function
Command to
AFE2000
00B: No function
01B: operated by digital keypad
10B: operated by Pr.01-04 setting
Bit 13~14
11B: change operation source
2000H
Bit 15 Reserved
2001H Frequency command
Bit 0 1: EF (external fault) on
Bit 1 1: Reset
Bit 2 1: B.B. ON
2002H
Bit 3-15 No function
2100H Error code: No function
Bit 0 1: No function
Bit 1 1: Operation status
Bit 2 1: No function
Monitor AFE2000
status
2119H
Bit 3 1: No function
Bit 4 1: No function
Bit 8 1: No function
Bit 9 1: No function
Bit 10
1: Operation command controlled by
communication interface
Bit 11 1: Parameters have been locked
Bit 12 1: enable to copy parameter from keypad
Bit 13-15 Reserved
211AH Phase Lock (PLL) Frequency(FXXXX)
2104H Output current (AXXX.X)
