Electrical Installation Tester
Unpacking the Tester
3
Table 1. Standard Accessories (cont.)
Description
1651B EU
1652B EU
1653B EU
1651B UK
1652B UK
1653B UK
Part
Number
Test lead set, 600 V, Fused
Probe with alligator clips and
prods, set of spare GS38 tips -
Red, Blue, Green (Replacement
fuse is an F 10 A 600 V, 50 kA,
6.3 x 32 mm)
√ √ √ 2491989
CD ROM, Users Manual √ √ √ √ √ √ 3209538
Quick Reference Guide √ √ √ √ √ √ 3278157
Case, Tool Box, Yellow √ √ √ √ √ √ 1664213
Hard Case Insert, Foam,
Polyurethane
√ √ √ √ √ √ 2061011
Carrying Strap, Padded √ √ √ √ √ √ 2045406
Fluke-1653-2014, IR Adapter √ √ 2043365
Fluke Zero Adapter √ √ √ √ √ √ 3301338
Table 2. Country Specific Mains Cords
Mains Cord Cord Type Part Number
British BS1363 2061367
Schuko CEE 7/7 2061332
Denmark AFSNIT 107-2-DI 2061371
Australia/New Zealand AS 3112 2061380
Switzerland SEV 1011 2061359
Italy CEI 23-16/VII 2061344
