Electrical Installation Tester
Specifications
45
Continuity Testing (R
LO
)
Range
(Autoranging)
Resolution
Open Circuit
Voltage
Accuracy
20 Ω 0.01 Ω >4 V +(1.5 % + 3 digits)
200 Ω 0.1 Ω >4 V +(1.5 % + 3 digits)
2000 Ω 1 Ω >4 V +(1.5 % + 3 digits)
Note
The number of possible continuity tests with a fresh set of batteries is 3000.
Range R
LO
Test Current
7.5 Ω 210 mA
35 Ω 100 mA
240 Ω 20 mA
2000 Ω 2 mA
Test Probe Zeroing
Press the Z to zero the test probe.
Can subtract up to 2 Ω of lead resistance.
Error message for >2 Ω.
Live Circuit Detection
Inhibits test if terminal voltage >10 V ac detected
prior to initiation of test.
