![Fluke 1650B [45/62] Features by model](/views2/1005005/page45/bg2d.png)
Electrical Installation Tester
Specifications
37
Specifications
Features by Model
Measurement Function 1651B 1652B 1653B
Voltage & Frequency √ √ √
Wiring polarity checker √ √ √
Insulation Resistance √ √ √
Continuity & Resistance √ √ √
Loop & Line Resistance √ √ √
Prospective Earth Fault Current (PEFC)
Prospective Short-Circuit current (PSC)
√ √ √
RCD switching time √ √ √
RCD tripping level √
ramp test
√
ramp test
RCD variable current √
√ √
Automatic RCD test sequence √ √
Test pulse current sensitive RCDs (Type A) √ √
Earth Resistance √
Phase Sequence Indicator √
Other Features
Self-test √ √ √
Illuminated Display √ √ √
Memory, Interface
Memory √
Computer Interface √
Time and date
(When used with FlukeView software)
√
Software √
Included Accessories
Hard case
√ √ √
Remote control probe
[1]
√ √ √
Note
[1] Included with all 165XB versions except 1651B UK.
