![Fluke 1650B [52/62] Earth tests](/views2/1005005/page52/bg34.png)
165XB
Users Manual
44
Earth Tests
Limit Value Maximum Display Value
10 8.8
20 17.8
30 26.8
40 35.8
50 44.8
60 53.8
70 62.8
80 71.8
90 80.8
100 89.8
200 179.8
300 268.0
400 358.0
500 448.0
600 538.0
700 628.0
800 718.0
900 808.0
1000 898.0
2000 1798.0
AC Voltage Measurement (V)
Range Resolution
Accuracy
50Hz - 60Hz
Input
Impedance
Overload
Protection
500 V 0.1 V 0.8 % + 3 3.3 MΩ 660 V rms
