Fluke 1650B [61/62] Operating uncertainties per en 61557
![Fluke 1650B [61/62] Operating uncertainties per en 61557](/views2/1005005/page61/bg3d.png)
Electrical Installation Tester
Specifications
53
Operating Uncertainties per EN 61557
Volts
EN 61557-1
RLo
EN 61557-4
RISO
EN 61557-2
Zi
EN 61557-3
dT
EN 61557-6
IdN
EN 61557-6
RE
EN 61557-5
Intrinsic
Uncertainty A
0.80 % 1.50 % 10.00 % 6.00 % 1.00 % 5.00 % 3.50 %
Influence
Quantity
Volts
EN 61557-1
RLo
EN 61557-4
RISO
EN 61557-2
Zi
EN 61557-3
dT
EN 61557-6
IdN
EN 61557-6
RE
EN 61557-5
E1 - Position 0.00 % 0.00 % 0.00 % 0.00 % 0.00 % 0.00 % 0.00 %
E2 - Supply
Voltage
0.50 % 3.00 % 3.00 % 3.00 % 3.00 % 2.75 % 2.25 %
E3 -
Temperature
0.50 % 3.00 % 3.00 % 3.00 % 3.00 % 2.25 % 2.75 %
E4 - Series
Interferences
Voltage
- - - - - - 1.50 %
E5 -
Resistance of
the probes
and auxiliary
earth
electrodes
- - - - - - 4.00 %
E6.2 - System
phase angle
- - - 1.00 % - - -
E7 - System
frequency
0.50 % 2.50 % 0.00 %
E8 - System
voltage
- - - 2.50 % 2.50 % 2.50 % 0.00 %
E9 -
Harmonics
- - - 2.00 % - - -
E10 - D.C.
Quantity
- - - 2.50 % - - -
