165XB
Users Manual
12
Input Terminals
Figure 4 shows the 165XB input terminals.
42 44
43
apx021f.eps
Item Description
p
L (Line)
q PE (Protective Earth)
r N (Neutral)
Figure 4. Input Terminals
Using the IR Port (Model 1653B Only)
The Model 1653B tester has an IR (infrared) port, see Figure 22, which allows
you to connect the tester to a computer and upload test data using a Fluke PC
software product. This automates your troubleshooting or recording process,
reduces the possibility of manual error and allows you to collect, organize, and
display test data in a format that meets your needs. See “Uploading Test
Results” on page 34 for additional information on using the IR port.
