Electrical Installation Tester
Specifications
51
Earth Resistance Test (R
E
)
Model 1653B Only. This product is intended to be used to measure installations
in process plants, industrial installations, and residential applications.
Range Resolution Accuracy
200 Ω 0.1 Ω ±(2 % + 5 digits)
2000 Ω 1 Ω ±(3.5 % + 10 digits)
Range: R
E
+ Rprobe Test Current
160 Ω 50 mA
1600 Ω 5 mA
16000 Ω 500 μA
52000 Ω 150 μA
Frequency Output Voltage
128 Hz 25 V
Live Circuit Detection
Inhibits test if terminal voltage >10 V ac
is detected prior to start of test.
Phase Sequence Indication
Model 1653B Only
Icon
Q icon Phase Sequence indicator is
active.
Display of Phase Sequence
Displays “1-2-3” in digital display field for
correct sequence. Displays “3-2-1” for
incorrect phase. Dashes in place of a
number indicate a valid determination
could not be made.
Mains Input Voltage Range
(phase-to-phase)
100 to 500 V
