165XB
Users Manual
2
Unpacking the Tester
The tester comes with the items listed in Table 1. If the tester is damaged or an
item is missing, contact the place of purchase immediately.
Table 1. Standard Accessories
Description
1651B EU
1652B EU
1653B EU
1651B UK
1652B UK
1653B UK
Part
Number
165X-8008 Probe, Multifunctional √ √ √ √ √ 2000757
Country Specific Mains Test Cord √ √ √ √ √ √
Various –
See
Table 2
TL-L1, Test Lead, Red √ √ 2044945
TL-L2, Test Lead Green √ √ √ 2044950
TL-L3, Test Lead Blue √ √ √ 2044961
Probe, Test, Banana Jack, 4 mm
Tip, Red
√ √ 2099044
Probe, Test, Banana Jack, 4 mm
Tip, Green
√ √ √ 2065297
Probe, Test, Banana Jack, 4 mm
Tip, Blue
√ √ √ 2068904
102-406-003, Probe cap,GS-38
Red
√ √ 1942029
102-406-002, Probe cap,GS-38
Green
√ √ √ 2065304
102-406-004, Probe cap,GS-38
Blue
√ √ √ 2068919
AC285-5001,175-276-013 AC285
Large crocodile clip, Red
√ √ 2041727
AC285-5001-02,175-276-012
AC285 Large crocodile clip, Green
√ √ √ 2068133
AC285-5001-03,175-276-0114
AC285 Large crocodile clip, Blue
√ √ √ 2068265
