165XB
Users Manual
6
Table 4. Pushbuttons (cont.)
No. Button Description
O
U
• Scroll memory locations.
• Set memory location codes.
• Scroll Auto test results.
• Adjust current for VAR function.
• Display results if noise is present.
P 3
• RCD type: AC (standard), S, or A (pulsed DC).
• Memory RECALL.
• Battery test.
• Loop R
E
/ I
K
Q 4
• RCD test polarity (0, 180 degrees).
• Insulation test voltage (50, 100, 250, 500, or 1000 V).
• Memory CLEAR.
R O
Turns the tester on and off. The tester will also shut off
automatically is there is no activity for 10 minutes.
S A Turns the backlight on and off.
T T
Starts the selected test.
The T key is surrounded by a “touch pad”. The touch pad
measures the potential between the operator and the
tester’s PE terminal. If you exceed a 100 V threshold, the
D symbol above the touch pad is illuminated.
