![Fluke 345 [68/80] W power](/views2/1005175/page68/bg44.png)
345
Users Manual
54
WPower
The measured power and associated variables for this function are described in
Table 7.
Table 7. Power
Measurement Notation Scales and
Ranging
Associated Items and
Comments
Power kW
Apparent Power kVA
Reactive Power kVAR
Power Factor* PF
Power Factor in
degrees (cos φ)*
PF°
Displacement Power
Factor*
DPF
Displacement Power
Factor in degrees
(cos φ)*
DPF°
Voltage Vac(1)
Current Iac(1)
N/A Frequency also
indicated
Minimum and
maximum of all values
Recording of average
values available
Energy** kWHr
Apparent energy** kVAHr
Reactive energy** kVARHr
Ampere hours** AHr
Measurement of these
items is started in REC
and logging mode.
Total run time indicated
on the display.
* Selectable through instrument setup menu
** Available in power logging mode
