Power Quality Clamp Meter
Measurement Function Overview
57
XThree-Phase Power
The three-phase power measurement and associated variables for this function
are described in Table 8.
Table 8. Three Phase Power
Measurement Notation Scales and
Ranging
Associated Items and
Comments
Power kW
Apparent Power kVA
Reactive Power kVAR
Power Factor* PF
Power Factor in
degrees (cos φ)*
PF°
Displacement
Power Factor*
DPF
Displacement
Power Factor in
degrees (cos φ)*
DPF °
Voltage Vac(1)
Current Iac(1)
N/A Frequency also indicated
Minimum and maximum
of all values
Recording of average
values available
Energy** kWHr
Apparent
energy**
kVAHr
Reactive energy** kVARHr
Ampere hours** AHr
Measurement of these
items is started in REC
and logging mode
Total run time indicated
on the display.
* Selectable through instrument setup menu
** Available in power logging mode
