Page 22 – DSS Keys
INDeX 9.1 2030/50/60 38DHB0002UKCL - Issue 5 (12/00)
BLF Status Lamps
The DSS keys on 2050 & 2060 phones incorporate dual-colour BLF
lamps. These show the status of the number stored under the DSS
key.
Red BLF Lamp Signals: Calls to/from other extensions.
• Slow Flash: Call on line parked at another extension.
• Fast Flash: Extension ringing.
• Solid: Extension or line busy.
Green BLF Lamp Signals: Calls to your extension.
• Slow Flash: Call on line parked at your extension.
• Fast Flash: External call ringing your extension.
• Solid: Call connected or held at your extension.
Alternate Green/Red Lamp Signal: Pilot Number.
• Slow Flash: Caller ringing pilot number.
DSS Key Label
Next to the DSS keys is a label. You can remove the label cover to
write on the card below. You can also remove the label cover under
the handset using the same method (it has a single pin hole on the
bottom edge).
To remove the label cover:
1. Insert a fine but not sharp point (e.g. end of a paper-clip) into one
pin hole. Squeeze the label to the right.
2. Repeat with the other pin hole.
3. Lift the label cover clear and remove the card insert.
To replace the label cover:
1. Replace the card insert.
2. Slide the tabs on the right-hand edge of the label cover into their
slots.
3. Bow the label cover to slip the tabs on the left-hand edge of the
label cover into their slots.
DSS Key Label Template
A template for printing DSS key labels exists. It can be used with
Word for Windows 2, 6 or 7. Contact your System Manager for a
copy of the template, alternatively you can obtain it from our internet
site (http://www.sdxplc.com).
