The Digital Controller ESIE07-05
2–12 Part 2 – Functional Description
3
1
2
4
5
1.4.4 Meaning of the Driver EEXV Status LEDs
Normal conditions Under normal conditions five(5) LED indicates:
■ POWER: (yellow) remains On in presence of supply. Remains Off in case of battery operation
■ OPEN: (green) Flashing during the valve opening. On when valve is fully open.
■ CLOSE: (green) Flashing during the valve closing. On when valve is fully close.
■ Alarm: (red) On or flashing in case of hardware alarm.
■ pLAN: (green) On during the normal working of pLAN.
Alarm situations In presence of critical alarm situations, the combination of the LED’s will identify the alarm as shown
below. In case more than one alarm is present, the alarm with the highest priority will be visualized.
Highest priority is level 7.
Alarms that stop the system PRIORITY LED OPEN LED CLOSE LED POWER LED ALARM
Eprom reading error 7 Off Off On Flashing
Valve open in case of lack of
supply
6 Flashing Flashing On Flashing
At start up, wait for battery
loading (parameter……….)
5 Off On Flashing Flashing
Other alarms PRIORITY LED OPEN LED CLOSE LED POWER LED ERROR
Motor connection error 4 Flashing Flashing On On
Probe error 3 Off Flashing On On
Eeprom writing error 2 - - On On
Battery error 1 - - Flashing On
pLAN LED pLAN
Connection OK On
Driver connection or address error = 0 Off
The Pco Master does not answer Flashing
ESIE07-05.book Page 12 Friday, December 21, 2007 3:21 PM
