Daikin EWWQ440AJYNN/A [24/130] Addressing of plan
![Daikin EWWQC20AJYNN/A [24/130] Addressing of plan](/views2/1658957/page24/bg18.png)
ESIE07-05 The Digital Controller
Part 2 – Functional Description 2–13
3
2
4
5
1
1.4.5 Addressing of pLAN
To get the correct functionality of the pLAN net system, it is necessary to address correctly all the
installed components. Each component has a series of microswitches that must be set as specified in
the table below.
pLAN component Microswitches
123456
Local DISPLAY OFF OFF OFF OFF ON OFF
Remote DISPLAY
(if available)
ON OFF OFF OFF ON OFF
COMP. BOARD #1
ON OFF OFF OFF OFF OFF
COMP. BOARD #2
OFF ON OFF OFF OFF OFF
COMP. BOARD #3
ON ON OFF OFF OFF OFF
COMP. BOARD #4
OFF OFF ON OFF OFF OFF
DRIVER EXV #1
ON OFF ON OFF OFF OFF
DRIVER EXV #2
ON ON ON OFF OFF OFF
DRIVER EXV #3
ON OFF OFF ON OFF OFF
DRIVER EXV #4
ON ON OFF ON OFF OFF
ESIE07-05.book Page 13 Friday, December 21, 2007 3:21 PM
