The Digital Controller ESIE07-05
2–40 Part 2 – Functional Description
3
1
2
4
5
Compressors
minimum load
This screen shows the Compressors minimum load.
Time download
compressor
This screen shows the Time download compressor.
Minimum
evaporator ∆T
This screen shows the Minimum evaporator ∆T.
DT to reload
compressor
This screen shows the ∆T to reload compressor.
Comp. Min load
%
025
Time to download
compressor
s
30
Min Evap DT
Max Time
min
015
˚C
1.0
DT to reload and
reunload comp
˚C
x.x
