The Digital Controller ESIE07-05
2–36 Part 2 – Functional Description
3
1
2
4
5
Enable evaporator flow alarm YES (MASTER); NO (SLAVES)
Enable condenser flow alarm YES (MASTER); NO (SLAVES) Solo WHS
Evaporator flow alarm delay (if
enabled)
■ STARTUP DELAY = 20 s
■ OPERATING DELAY = 5 s
High discharge temperature setpoint
■ SETPOINT = 120 °C
■ DIFFERENTIAL = 5 °C
High pressure alarm setpoint
■ SETPOINT = 20.5 bar
■ DIFFERENTIAL = 05.0 bar
Low pressure alarm setpoint
■ SETPOINT = 01.0 bar
■ DIFFERENTIAL = 00.5 bar
Delay low pressure alarm
■ STARTUP DELAY = 120 s
■ OPERATING DELAY = 60 s
■ Ratio alarm setpoint
■ Min Load
■ Max Load
1.4
1.8
Delay pressure Ratio alarm
■ STARTUP DELAY = 180 s
■ OPERATING DELAY = 90 s
Transducers high
pressure alarm
Setpoint
Diff.
bar20.5
05.0
bar
Transducers low
pressure alarm
Setpoint
Diff.
bar-01.0
00.5
bar
Low pressure alarm
delays
Startup delay
Run delay
s120
060
s
Pressure ratio alarm
Min Load Setp
Max Load Setp
1.4
1.8
Pressure ratio alarm
Startup delay
Run delay
180
090
s
s
