ESIE07-05 Functional Control
Part 2 – Functional Description 2–51
3
2
4
5
1
Compressors
unload and
shutdown
management (4
compressors)
16a (T in unload
band)
Fixed at 75% Fixed at 75% Unload up to 50% Start
16b (T out unload
band)
Fixed at 75% Fixed at 75% Fixed at 75% Start
17 Fixed at 75% Fixed at 75% Fixed at 75% or
50%
Load up to 50%
18 (if lag 2 at 50%) Fixed at 75% Fixed at 75% Load up to 75% Fixed at 50%
19 Fixed at 75% Fixed at 75% Fixed at 75% Load up to 75%
20 Load up to 100% Fix a/Fixed at 75% Fix a/Fixed at 75% Fix a/Fixed at 75%
21 Fixed at 100% Fixed at 100% Fixed at 100% Fixed at 75%
22 Fixed at 100% Fixed at 100% Load up to 100% Fixed at 75%
23 Fixed at 100% Fixed at 100% Fixed at 100% Load up to 100%
24 Fixed at 100% Fixed at 100% Fixed at 100% Fixed at 100%
Step n. Leader Comp. Lag 1 Comp. Lag 2 Comp. Lag 3 Comp.
Step n. Leader Comp. Lag 1 Comp. Lag 2 Comp. Lag 3 Comp.
0 100% 100% 100% 100%
1 Fixed at 100% Fixed at 100% Fixed at 100% Unload up to 75%
2 Fixed at 100% Fixed at 100% Unload up to 75% Fixed at 75%
3 Fixed at 100% Unload up to 75% Fixed at 75% Fixed at 75%
4 Unload up to 75% Fixed at 75% Fixed at 75% Fixed at 75%
5 Fixed at 75% Fixed at 75% Fixed at 75% Unload up to 50%
6 Fixed at 75% Fixed at 75% Unload up to 50% Fixed at 50%
7 Fixed at 75% Fixed at 75% Fixed at 50% Unload up to 25%
8 If T is approaching SetP – Waiting
8a (T in load band) Fixed at 75% Fixed at 75% Load up to 75% Stop
8b (T not in load
band)
Fixed at 75% Fixed at 75% Fixed at 50% Stop
9 (if lag 2 at 75%) Fixed at 75% Fixed at 75% Fixed at 75% Off
10 Fixed at 75% Unload up to 50% Fixed at 50% Off
11 Fixed at 75% Fixed at 50% Fixed at 25% Off
12 If T is approaching SetP – Waiting
13a (T in load
band)
Fixed at 75% Load up to 75% Stop Off
13b (T not in load
band)
Fixed at 75% Fixed at 50% Stop Off
14 (lag 1 at 75%) Fixed at 75% Unload up to 50% Off Off
15 Unload up to 50% Fixed at 50% Off Off
16 Fixed at 50% Unload up to 25% Off Off
17 If T is approaching SetP – Waiting
ESIE07-05.book Page 51 Friday, December 21, 2007 3:21 PM
