Functional Control ESIE07-05
2–50 Part 2 – Functional Description
3
1
2
4
5
Unit shutdown
Compressors start
up and loading
management
(4 compressors)
UNIT ALARM 005
(Evap Flow Alarm)
Unit Shutdown request
Evaporator pump shutdown
Flow switch opening within 180 s
(user set)
Compressors shutdown
(see compressors shutdown in startup
and management procedure)
Step n. Leader Comp. Lag 1 Comp. Lag 2 Comp. Lag 3 Comp.
0 Off Off Off Off
1 If (T – SetP) < Start up DT & Cooling
or (SetP – T) < Start up DT & Heating
Waiting
2 Start Off Off Off
3 Load up to 75% Off Off Off
4 If T in Regulation Band Wait interstage time
5 If T is approaching SetP – Waiting
6a (T in unload
band)
Unload up to 50% Start Off Off
6b (T not in unload
band)
Fixed at 75% Start Off Off
6 Fixed at 75% or
50%
Load up to 50% Off Off
7 (If leader at 50%) Load up to 75% Fixed at 50% Off Off
8 Fixed at 75% Load up to 75% Off Off
9 If T in Regulation Band Wait interstage time
10 If T is approaching SetP – Waiting
10a (T inun load
band
Fixed at 75% Unload up to 50% Start Off
10b (T not in
unload band)
Fixed at 75% Fixed at 75% Start Off
11 Fixed at 75% Fixed at 75% or
50%
Load up to 50% Off
12 (If lag 1 at 50%) Fixed at 75% Load up to 75% Fixed at 50% Off
13 Fixed at 75% Fixed at 75% Load up to 75% Off
14 If T in Regulation Band Wait interstage time
15 If T is approaching SetP – Waiting
ESIE07-05.book Page 50 Friday, December 21, 2007 3:21 PM
