ESIE07-05 The Digital Controller
Part 2 – Functional Description 2–45
3
2
4
5
1
Alarm table -
Driver1
Alarm table -
Driver2
Code Alarm description
Compressor
off
Fan off
Pump
off
System
off
Reset
(auto/man)
Delay Enabling
AL60 Driver1 - Probe error *Circuit man selectable
AL61 Driver1 - Step motor error *Circuit man
AL62 Driver1 - Eeprom error *Circuit man selectable
AL63 Driver1 - Battery error *Circuit man selectable enabling
AL64 Driver1 - High pressure man selectable
AL65 Driver1 - Low pressure *Circuit man selectable enabling
AL66 Driver1 - Super-heat man selectable
AL67 Driver1 - Valve not closed
during stop
man
AL68 Driver1 - wait for valve
reopening
man
AL69 Driver1 - wait for battery
recharge
man
AL70 Driver1 - wait for eeprom
restart
man
Code Alarm description
Compressor
off
Fan off
Pump
off
System
off
Reset
(auto/man)
Delay Enabling
AL80 Driver2 - Probe error *Circuit man selectable
AL81 Driver2 - Step motor error *Circuit man
AL82 Driver2 - Eeprom error *Circuit man selectable
AL83 Driver2 - Battery error *Circuit man selectable enabling
AL84 Driver2 - High pressure man selectable
AL85 Driver2 - Low pressure *Circuit man selectable enabling
AL86 Driver2 - Super-heat man selectable
AL87 Driver2 - Valve not closed
during stop
man
AL88 Driver2 - wait for valve
reopening
man
AL89 Driver2 - wait for battery
recharge
man
AL90 Driver2 - wait for eeprom
restart
man
ESIE07-05.book Page 45 Friday, December 21, 2007 3:21 PM
