ESIE07-05 The Digital Controller
Part 2 – Functional Description 2–31
3
2
4
5
1
1.5.4 Input/Output Menu (I/O Menu)
Introduction This menu shows the parameters listed below.
Software type,
release
This screen shows the Software type, release
Digital Input and
Output status (C, O)
This screen shows the Digital Input and Output status (C, O)
Analog Output
value (Vdc)
This screen shows the Analog Output value (Vdc)
Inlet and outlet
water temperature,
ambient temp
This screen shows the Inlet and outlet water temp., ambient temperature
Compressor
discharge
temperature and
load
This screen shows the Compressor discharge temperature and load
Condensing and oil
pressure
This screen shows the Condensing and oil pressure
Code:
v.
xxxx
xx/xx/xx
software version
xxxxxxxx
1.xxx
Digital inputs
xxxxxxxxxxxxxxxxxxxxxxx (C or 0)
(C or 0)xxxxxxxxxxxxxxxxxxxxxxx
Digital outputs
Analog outputs:
xx.x V
xx.x V
xx.x
V
Y3:
Y2:
Y1:
Analog inputs:
B1: xx.x ˚C
xx.x ˚C
xx.x ˚C
in water
out water
cond out
B5:
B2:
Analog inputs:
B4: xx.x ˚C
xx.x mA
xx.x
%
Del temp
slide v.
B6:
B3:
Analog inputs:
xx.x bar
xx.x
bar
oil pr.
cond pr.
B8:
B7:
ESIE07-05.book Page 31 Friday, December 21, 2007 3:21 PM
