ESIE07-05 Functional Control
Part 2 – Functional Description 2–79
3
2
4
5
1
2.22.2 Pressure ratio alarm delay
Function
description
Delay time before the unit goes into pressure ratio alarm.
■ start up delay: At start up the unit will start to check the pressure ratio after the 180 seconds start
up delay timer.
■ run delay: When the unit is in operation, the pressure ratio can be below the setpoint for a
specified time before the unit will trip on pressure ratio alarm.
2.22.3 High Oil DP Alarm
Function
description
When the pressure drop across the oil filter becomes too big (higher than 2.5 bar) the unit will shut
down and generate the high oil DP alarm.
Alarm activates when DP is higher than 2.5 bar (default) for 20 seconds (default).
DP = (HP – oil pressure)
Pressure Ratio Alarm
Start-Up Delay
Run Delay
180 s
90 s
HP Oil Pressure senso
r
Oil Filter
(inside compressor)
High Oil DP Alarm
Setpoint
Delay
2.5 bar
20 s
ESIE07-05.book Page 79 Friday, December 21, 2007 3:21 PM
