Daikin EWWQ440AJYNN/A [80/130] Pump down configuration at compressor stop

Daikin EWWQC14AJYNN/A [80/130] Pump down configuration at compressor stop

Functional Control ESIE07-05

2–74 Part 2 – Functional Description

2.19 Pump Down Configuration at Compressor Stop

Introduction When the unit is switched off (local, remote, thermostat) the pump down procedure will be executed.

Function

description

Pump down procedure:

■ request to shut down compressor

■ close electronic expansion valve

■ stop compressor or when one of the two conditions is met:

■ max time of pump down = 30 seconds

■ LP is below 1.2 bar

Pump Down Config

Enable

Max time

Min Press.

30 s

1.2 bar
