ESIE07-05 Functional Control

Part 2 – Functional Description 2–77

2.21 LP alarm delay

Function

description

Delay timer before the unit goes into LP alarm.

■ start delay: At start up the unit has a delay of 120 seconds before the unit can trip on LP alarm (low

pressure bypass timer)

■ run delay: When the unit is in operation, the low pressure can be below the LP alarm setpoint for

a specified time before the unit will trip on LP alarm.

Low Press. Alarm Delays

Start-Up Delay :

Run Delay :
