Daikin EWWQ440AJYNN/A [49/130] Buffer alarm menu

Daikin EWWQ650AJYNN/A [49/130] Buffer alarm menu

ESIE07-05 The Digital Controller

Part 2 – Functional Description 2–43

1.5.9 Buffer Alarm Menu

Introduction Using this menu you can consult the last ten alarms of every chiller circuit.

Each mask displays the date, time and description of the alarm. Pressing the enter key when an alarm

description is displayed shows the operating conditions at the time the alarm occurred (temperatures,

pressures, expansion valve status and compressor load).

Screens

DD/MM/YY

Phase Alarm

hh/mm

In. Wat. T.

Out. Wat. T.

Suct. Press.

Disc. Press.

xx.x ˚C

xxx.x

˚C

xx.x ˚C

xx.x bar

13.1bar

025

xxxx

Evap. Temp.

Suct. Temp.

Cond. Temp.

Disc. Temp.

Oil Press.

Comp. Load
