ESIE07-05 The Digital Controller
Part 2 – Functional Description 2–33
3
2
4
5
1
1.5.5 Manufacturer Menu
Introduction In this menu you can set all manufacturer data. Password is required before the operation. The
parameters can be modified only by trained persons.
Warning: Improper Setpoint or value, can cause erratic chiller operation and damage to the
chiller. Please use caution whenever changing set points or value.
Overview
Unit Configuration
■ 00 = Air cooled Chiller
■ 01 = Water/Water Heat Pump
■ 02 = Water/Water Pursuit Chiller
■ 03 = Water cooled Chiller
Probe enable (Master Board) B1, B2, B4, B6, B7, B8
Probe enable (Slave Board) B4, B6, B7, B8
Discharge probe type (B4) PT1000/NTC
Fase monitor type UNIT
■ Pid parameter
■ Integrative time
■ Derivative Time
200sec
060sec
Unit config.
03
CHILLER
WATER COOLED
Probes enable
U: X
B4: S
B7: S
B1: S
B5: S
B8: S
B2: S
B6: N
B3: -
Discharge Temp.
Probe Type PT1000
Phase Monitor Type
UNIT
Temp. Regulation
Interval Time s200
s060
Derivative Time
ESIE07-05.book Page 33 Friday, December 21, 2007 3:21 PM
