ESIE07-05 The Digital Controller
Part 2 – Functional Description 2–35
3
2
4
5
1
Compressor loading pulse time ■ PULSE TIME = 0.3 s
■ MIN. PULSE PERIOD = 20 s
■ MAX. PULSE PERIOD = 90 s
Pumpdown configuration
■ ENABLING: YES
■ MAX. TIME= 60 s
■ MIN.PRESSURE= 0.5 bar
High pressure stage hold 17.5 bar
High pressure stage down 18.5 bar
Low pressure stage hold 1.7 bar
Low pressure stage down 1.2 bar
■ Antifreeze prevent
■ Setpoint
■ Diff.
3.5°C
1.0°C
Condensation enable mode NONE
Enable oil temperature control Y
Compressor Loading
Min pulse period
Max pulse period
Pulse time
00.3
05
90
s
s
s
Pump down config.
Max time
Min press.
Enable
030
1.2
S
s
barg
Cond. P. hold
Evap. P. hold
Evap. P. down
Cond. P. down
-00.5
18.5
17.5
-00.8
bar
bar
bar
bar
Freeze prevent
Setpoint
Diff.
03.0
01.0
˚C
˚C
Condensation
Enable
Type
Fans Steps
NONE
-
-
Enable Oil Heating
control
S
ESIE07-05.book Page 35 Friday, December 21, 2007 3:21 PM
