ESIE07-05 The Digital Controller
Part 2 – Functional Description 2–39
3
2
4
5
1
EXV driver state This screen shows the EXV driver state.
Pressure and
temperature
sensors correction
These screens show the Pressure and temperature sensors correction.
Compressor run
hours correction
This screen shows the Compressor run hours correction.
Correction of
compressor starts
This screen shows the Correction of compressor starts.
Correction of
evaporator
pump/condenser
pump and run
hours
These screens show the Correction of evaporator pump/condenser pump and run hours.
EXV Driver State
Batt. Resist.
Batt. Voltage
xxx.x
xx.x
offset
Input probes
U: X
B1: 0.0
B3: ---
B2: 0.0
B4: 0.0
offset
Input probes
U: X
B5: 0.0
B7: 0.0
B6: ---
B8: 0.0
Cond. h. count
Treshold 010x1000
U: X
Y/N
xxxxxx
Reset
Adjust
Comp. Starts
U: X
Y/N
xxxxxx
Reset
Adjust
Evap. pump h. count
Treshold 010x1000
Y/N
xxxxxx
Reset
Adjust
Cond. pump h. count
Treshold 010x1000
Y/N
xxxxxx
Reset
Adjust
ESIE07-05.book Page 39 Friday, December 21, 2007 3:21 PM
