Special Control SiBE311209
105 Function
8. Special Control
8.1 Pump down Residual Operation
If the liquid refrigerant stays in the evaporator at the startup of a compressor, this liquid refrigerant enters the
compressor, thus resulting in diluted oil in the compressor and then degraded lubrication performance.
Consequently, in order to recover the refrigerant in the evaporator while the compressor stops, the pump down residual
operation is conducted.
8.1.1 Pump down Residual Operation in Cooling Operation (Outdoor Unit)
Actuator
Electric
symbol
STEP 1 STEP 2
Master unit
operation
Slave unit
operation
(RTSYQ20PAY1
only)
Master unit
operation
Slave unit
operation
(RTSYQ20PAY1
only)
Compressor 1 M1C 124 Hz
OFF
52 Hz
OFFCompressor 2 M2C OFF OFF
Compressor 3 M3C OFF OFF
Outdoor unit fan 1 M1F
Fan control OFF Fan control OFF
Outdoor unit fan 2 M2F
Electronic expansion valve (Main) Y1E 480 pls 0 pls 240 pls 0 pls
Electronic expansion valve
(Subcooling)
Y3E 0 pls 0 pls 0 pls 0 pls
Electronic expansion valve
(Refrigerant charge)
Y2E 80 pls 80 pls 80 pls 80 pls
Solenoid valve (Refrigerant
regulator gas vent pipe)
Y1S OFF OFF OFF OFF
Four way valve (Heat exchanger
switch)
Y3S OFF OFF OFF OFF
Solenoid valve (Refrigerant
regulator liquid pipe )
Y4S OFF OFF OFF OFF
Solenoid valve (Hot gas) Y5S OFF OFF OFF OFF
Solenoid valve (Main bypass)
Y6SONONONON
Solenoid valve (Refrigerant
regulator discharge pipe)
Y7S OFF OFF OFF OFF
Solenoid valve (Refrigerant
regulator discharge pipe)
Y8S OFF OFF OFF OFF
Solenoid valve (Heat exchanger
hot gas)
Y9SONONONON
Four way valve (High/low pressure
gas pipe switch)
Y2SONONONON
Ending conditions
• 5 min.
• Master unit Pe < 0.49 MPa
• Master unit Pc > 2.94 MPa
• Master unit Tdi > 110°C
• Master unit Tp > 125°C
• 45 sec.
• Master unit Pe < 0.24 MPa
• Master unit Tp > 160°C
• Master unit Pc > 3.14 MPa
OR
OR
