Field Setting SiBE311209
177 Test Operation
Supplementation on (2) and (3).
When switching cool/heat for each adaptor PCB with the use of more than one adaptor PCB,
set the address of the external control adaptor for outdoor unit PCB DS1 and DS2
so that it
matches the unified cool/heat address
of outdoor unit main PCB.
Address setting for
d
and
e
(Set lower 5 digits with binary number.) [No.0 to No.31]
DS2 · DS1
External
control
adaptor No.0
Outdoor
unit group
master No.0
Outdoor
unit group
slave No.0
Outdoor
unit group
slave No.0
C/H group address
khhhhhh
DS2 · DS1
External
control
adaptor No.1
Outdoor
unit group
master No.1
Outdoor
unit group
slave No.1
C/H group address
khhhhhk
DS2 · DS1
External
control
adaptor No.2
Outdoor
unit group
master No.2
Outdoor
unit group
slave No.2
Outdoor
unit group
slave No.2
C/H group address
khhhhkh
DS2 · DS1
External
control
adaptor No.3
Outdoor
unit group
master No.3
Outdoor
unit group
slave No.3
C/H group address
khhhhkk
Address
No.
No 0
No 2
No 1
No 3
No 4
No 30
No 31
Outdoor unit PCB LED
Set with setting mode 2
kh hhhhh
0
kh hhhhk
1
kh hhhkh
2
kh hhhkk
3
kh hhkhh
4
kh kkkkh
30
kh kkkkk
31
k
: ON
h
: OFF
External control adaptor for outdoor unit
DS2 DS1
0
1
2
3
4
30
31
Upper position (ON) lower position (OFF)
(The shaded part shows knob)
