Specifications SiBE311209
9 Specifications
1. Specifications
1.1 Outdoor Units
Heat Pump 50Hz <RTSYQ-PA>
Notes:
+
1 Indoor temp. : 27°CDB, 19°CWB / Outdoor temp. : 35°CDB
Equivalent piping length : 7.5m, level difference : 0m
Function unit length : 6m
+
2 Indoor temp. : 20°CDB / Outdoor temp. : 7°CDB, 6°CWB
Equivalent piping length : 7.5m, level difference : 0m
Function unit length : 6m
+
3 Indoor temp. : 20°CDB / Outdoor temp. : -10°CWB
Equivalent piping length : 7.5m, level difference : 0m
Function unit length : 6m
+
4 Displacement value are at nominal capacity.
+
5 Motor output are nominal.
Model Name RTSYQ10PAY1
Independent Unit
Outdoor Unit RTSQ10PAY1
Function Unit BTSQ20PY1
+
1 Cooling Capacity kW 28.0
+
2 Heating Capacity kW 31.5
+
3 Heating Capacity (-10°CWB) kW 28.0
Casing Color Ivory White 5Y7.5/1
Dimensions: (H×W×D) mm (1,680×930×765)+(1,570×460×765)
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Displacement
+
4 m³/h (13.72+10.53)+16.9
Number of Revolutions r.p.m (6300, 2900), 7980
Motor Output×Number
of Units
+
5
kW (2.2+4.5)+4.7
Starting Method Soft Start
Fan
Type Propeller Fan
Motor Output kW 0.75×1
Airflow Rate m³/min 185
Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ9.5 C1220T (Brazing Connection)
Suction Gas Pipe mm φ22.2 C1220T (Brazing Connection)
Mass (Weight) kg 257+110
Operating Sound dB(A) 60
Safety Devices High Pressure Switch, Fan Driver Overload Protector, Overcurrent Relay, Inverter Overload Protector
Defrost Method Deicer
Capacity Control % 9~100
Refrigerant
Refrigerant Name R-410A
Charge kg 10.5
Control Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No. C: 4D076315
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
