SiBE311209 Troubleshooting by Remote Controller
Service Diagnosis 198
Service Menu Item 2 Remarks
1.Model Name Display 1.Unit No. Select the Unit No. you want to check.
2.Indoor unit
3.Outdoor unit
2.Operating Hours
Display
1.Unit No. Select the Unit No. you want to check.
2.Indoor unit operating time All of these are displayed in hours.
3.Indoor unit fan operation
4.Indoor unit energized time
5.Outdoor operating time
6.Outdoor unit fan 1 operation
7.Outdoor unit fan 2 operation
8.Outdoor comp. 1 operation
9.Outdoor comp. 2 operation
3.Indoor Status Display
1/2
1.Unit No. Select the Unit No. you want to check.
2.FAN Tap, speed (rpm)
3.FLAP Swing, fixed
4.Speed Fan speed (rpm)
5.EV Degree that electronic expansion valve is open
(pls)
6.MP Drain pump ON/OFF
7.52H Electric heater ON/OFF
8.Hu Humidifier ON/OFF
9.Anti-freezing Anti-freezing control ON/OFF
3.Indoor Status Display
2/2
1.Unit No. Select the Unit No. you want to check.
VRV
2.Th1 Suction air thermistor
3.Th2 Heat exchanger liquid pipe thermistor
4.Th3 Heat exchanger gas pipe thermistor
5.Th4 Discharge air thermistor
6.Th5 —
7.Th6 —
4.Outdoor Status
Display
1.Unit No. Select the Unit No. you want to check.
2.FAN Tap 1 Fan tap
3.COMP Compressor power supply frequency (Hz)
4.EV1 Degree that electronic expansion valve is open
(pls)
5.SV1 Solenoid valve ON/OFF
VRV
6.Th1 —
7.Th2 —
8.Th3 —
5.Error Display
Selection
1.Warning display ON Displays a warning on the screen if an error
occurs.
2.Warning display OFF No warning is displayed.
3.Error display ON Displays the error on the screen.
4.Error display OFF Displays neither errors nor warnings.
6.Unit No. Transfer 1.Current Unit No. A unit No. can be transferred to another.
2.Transfer Unit No.
7.Sensor Address
Display
{ Unit No.: 0 - 15 Select the Unit No. you want to check.
{ Code
00:
01:
02:
03:
04:
05:
06:
07:
08:
09:
Remote controller thermistor (°C)
Suction air thermistor (°C)
Heat exchanger liquid pipe thermistor (°C)
Heat exchanger gas thermistor (°C)
Indoor unit address No.
Outdoor unit address No.
BS unit address No.
Zone control address No.
Cooling/heating batch address No.
Demand/low-noise address No.
{ Data The corresponding data will be displayed, based
on the Unit No. and Code selected.
