PLANET Mesh Network Manager Guide
PLANET Mesh Network Manager Guide
Page
101 of 126
3) WAN Downlink Speed
• Define the download speed of the WAN interface
• Data type: Integer, in the range of 5 and 100 Mbps
4) User Uplink Speed
• Define the user default upload speed.
• Data type: Integer, in the range of 32 and 65535 kbps
5) User Downlink Speed
• Define the user default download speed
• Data type: Integer, in the range of 32 and 65535 kbps
Parameters (Traffic Shaping Table)
1) Protocol
• The protocol to use.
• Available choice: UDP, TCP and Both
2) Port
• The port number
• Data type: Integer, in the range of 1 and 65535
3) Min Size
• The minimum size of the data packet
• Data type: Integer, in the range of 1 and 65535
4) Max Size
• The maximum size of the data packet
• Data type: Integer. in the range of 1 and 65535
5) Priority
• The priority to be assigned to the rule
• Available choice: Background, Video, Voice and Best Effort
6) Comment
• An optional comment regarding the table entry
• Data type: Display String
